R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable

  • R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable
  • R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable
  • R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable
  • R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable
  • R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable
Lieu d'origine Chine
Nom de marque KUB
Certification CE
Numéro de modèle 500 KUB
Quantité de commande min 1000
Prix 1 - 9 sets $4,073 >= 10 sets $3,870
Détails d'emballage D'autres
Délai de livraison 15 à 20 travaux
Conditions de paiement L/C, D/A, T/T
Capacité d'approvisionnement 1000 ensembles par an

Contactez-moi pour des aperçus gratuits et des bons.

whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Si vous avez n'importe quel souci, nous fournissons l'aide en ligne de 24 heures.

x
Détails sur le produit
Mettre en évidence

R404A Cold Storage Plant

,

Vegetable Cold Storage Plant
Laisser un message
Description de produit

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 0



Cold storage outer dimensions: 6*4.5*3m=81m3 for use temperature 0 to +12 ℃
Number Name Parameters
1 panels Thickness: 100mm/0.426mm,
Polyurethane double-sided color steel plate
2 door Hinged door
800*1800*100mm
Electric heating wire
Polyurethane double-sided color steel plate right door
3 Light 20W 220v 50hz
4 Condensing unit ZB38/5HP/R404A /380V 50HZ
5 Air cooler DD40/380volts/ 50 Hz /3Ph
electric defrost+Boom screws
+sewer heating line 4M
6 Expansion valve TE2
7 Control box NAK121/5.5KW
8 PVC water pipe 4m/pcs
9 copper pip Φ19
10 copper pipe Φ12
11 elbow Φ19
12 elbow Φ12
13 Insulation tube Φ19mm
14 Ties
15 P type elbow Φ19
16 slap Φ19



17

 slap Φ12
18 Wires
R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 1

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 2

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 3R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 4R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 5R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 6R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 7R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 8R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 9R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 10



R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 11

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 12

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 13

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 14R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 15R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 16

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 17

R404A Cold Storage Plant 81m³ Temperature 0 To 12℃ For Vegetable 18
